Gas Tight Cookie Production Line , 220V 3m Section Steel Belt Bakery Tunnel Oven

Place of Origin China
Brand Name Saimai
Certification CE Certificate, ISO 9000 Certificate
Model Number Customized
Minimum Order Quantity 1
Price Negotiable
Packaging Details Wooden case, Wooden pallet
Delivery Time 90days
Payment Terms T/T, L/C
Supply Ability 5Set/90-120 Working Days

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Voltage 220V/380V Material 304 Stainless Steel
Motor SIEMENS,SEW Application Cookies Maker
Warranty One Year After-sales Service Provided Engineers Available To Service Machinery Overseas,Field Installation,commissioning And Training,Free Spare Parts,Online Support
High Light

Gas Tight Cookie Production Line

,

Steel Belt 220V Bakery Tunnel Oven

,

3m Bakery Tunnel Oven

Leave a Message
Product Description

Industrial Commercial Production Line Cookie Baking Steel Belt Tunnel Oven



For industrial high capacity cookie production, the steel belt tunnel oven is necessary, the cookie are deposited on the steel belt directly and bake into oven. the heating system of tunnel oven are direct heated and indirect heated.



OVEN BODY

1. The oven is constructed gas-tight baking tunnel, divided into 3m/ section with gas-tight

connection between sections,Each section is connected with a frame.

2. The baking tunnels are insulated with high-quality insulation material, in order to reduce heat loss to a minimum.

3: View ports that can be opened are fitted at the oven sides for every zone.

4: The operating panel is fitted near the oven out feed. Operation can be from either right or left hand side.



TEMPERATURE CONTROL



STEEL BELT



1: Production transportation way: BY steel belt

2: Steel belt support: inside the oven: by Cast iron slide and Graphite slide support the belt,

Outside the oven, by ldler rollers support the steel belt.

3: Steel belt off tracking control: automatic off tracking control system, mainly be controlled pneumatically,assisted by the edge guide rollers .



PLC CONTROL SYSTEM PLC



1: An OMRON PLC system is used for the oven production control.

2: The touch screen associated with PLC system is installed on the side of oven for displaying the

operating conditions with related alarm messages if any.

3: The touch screen can be located on either the right or left-hand side of the oven.
